Any-to-Any 100 Ohm wireline switch-matrix
Broadband switch matrix for balanced 100 Ohm wireline telephony twisted pairs in a frequency band from DC up to 2 GHz optimized for typical RJ-45 300 MHz telecom patching. It is the ideal solution for automation of testing between a multiple of devices and DSLAM/DPU/Server ports as it allows for remote selection of devices independent of their physical connection in the laboratory. ASM 421 is stackable in steps of 8 to 32 ports up to 96 or 192 ports with a 4 to 1 concentration function towards 2, 4, or 8 simultaneous operational test channels.
- transparant matrix switch of signals up to 2 GHz
- multiple connections RJ 11/RJ45/Coax SMA
- computer controlled switching (CLI)
- Always guaranteed connections, no manual patching
- Overlook all current connections at a glance
- Keep track on configuration of connections
- 50, 75 or 100 Ohm Impedance neutral switching
- 35 milli seconds switching time
- Extreme low insertion loss < 0, 03 dB@10MHz
- > 1 mio connections
- Multi user Client Server topology
- Compact 19 Inch format
- Expandable with 50 Ohm Noise Generator output to a balanced 100 Ohm 'Noise injection' circuit
- Favorite solution of the broadband test expert/engineer
- Remotely and automatic configuration/change of connections
- Connect one time multiple devices / select and switch any device to the output port
- Automation of test benches
- Non interruptible LAN switch relay
- Ethernet layer 1 patch switching
- Optical electrical coaxial or wireline swicthing capability
- VDSL2 and G. fast Vectored Multi pair CPE DUT selection
- xDSL regression testing with multiple type of DSLAM's/DPU's
- Remote selection of Golden Reference CPE's and DSLAM (ports/blades)
- 2 pair or 8 pair bonding VDSL2 or G. fast test
- Mix of different CPE technologies (xDSL) towards different DSLAM/DPU blades
- Selection/mix of back to back testing with Interop and/or Performance tests over a Physical Layer Test platform
